Fuji Xerox Mono Black and White Production Printer

Fuji Xerox B9136 / B9125 / B9110 / B9100 Copier / Printer

Fuji Xerox B9136 / B9125 / B9110 / B9100 Black and White Production Printer
Fuji Xerox B9136 / B9125 / B9110 / B9100 Black and White Production Printer
Fuji Xerox B9136 / B9125 / B9110 / B9100 Black and White Production Printer


Fuji Xerox B9136 / B9125 / B9110 / B9100
Monochrome printer suits monochrome POD business.

​
  • Equipped with various copy and scan functions.
  • Print Speed: 136 ppm.
  • Continuous mass printing possible with High Capacity Feeders and High Capacity Stacker.
  • Latest finisher lineup. Cover insertion, three-sided trim, and saddle stitched booklet with square fold supported.
  • Simple Image Quality Adjustment (SIQA) makes alignment adjustment easy.
  • Able to register optimal print settings for each paper type.
  • Specification
  • Brochure
  • Video
Fuji Xerox B9136 / B9125 / B9110 / B9100
​
Basic Specifications / Print Function
Printing Resolution
​2400×2400 dpi
Continuous Print Speed (Banner Printing on long paper of up to 330.2 x 660.4 mm is available. Banner Printing on long paper is available for B9136, B9125, and B9110 Copier/Printer.)
A4
  • B9136: 136 ppm
  • B9125: 125 ppm
  • B9110: 110 ppm
  • B9100: 100 ppm
A3
  • B9136: 68 ppm
  • B9125: 62 ppm
  • B9110: 55 ppm
  • B9100: 50 ppm
​Paper Size (Banner Printing on long paper of 64 to 216 gsm is available. Banner Printing on long paper is available for B9136, B9125, and B9110 Copier/Printer.)
Tray 1, 2
  • Standard Size: Max A4, Min JIS B5
Tray 3, 4
  • Standard Size: Max A3, SRA3 (320×450 mm), Min A5 Custom Size: 139.7×182 mm to 330.2×488 mm
Bypass Tray (64 gsm paper)
  • Standard Size: Max A3, SRA3 (320×450 mm), Min A6 Custom Size: 100×148 mm to 330.2×488 mm (When larger size sheets are stacked on top of smaller size sheets.)
​Paper Weight
​Tray 1, 2, 3, 4
  • 52 to 216 gsm
Bypass Tray (64 gsm paper)
  • Standard Size: Max A3, SRA3 (320×450 mm), Min A6 Custom Size: 100×148 mm to 330.2×488 mm (When larger size sheets are stacked on top of smaller size sheets.)
Paper Tray Capacity (65 sheets for sizes exceeding A4)
Standard
  • 4050 sheets (1100 sheets+1600 sheets+550 sheets×2-tray+Bypass Tray 250 sheets)
Optional
  • B9136: High Capacity Feeder C1-D2: 2000 sheets×2, High Capacity Feeder C4-DS: 2000 sheets×2
  • B9125, B9110: High Capacity Feeder C1-D1: 2000 sheets×2, High Capacity Feeder B1-S: 2000 sheets×1, High Capacity Feeder C4-DS: 2000 sheets×2
  • B9100: High Capacity Feeder C1-D1: 2000 sheets×2, High Capacity Feeder B1-S: 2000 sheets×1
Max
  • B9136: 8050 sheets [Standard+ High Capacity Feeder C1-D2 or High Capacity Feeder C4-DS]
  • B9125, B9110: 8050 sheets [Standard+ High Capacity Feeder C1-D1 or High Capacity Feeder C4-DS]
  • B9100: 8050 sheets [Standard+ High Capacity Feeder C1-D1]
Output Tray Capacity
Depends on the spec. of output option
Power Supply
AC200-240 V+/-10 %, 15 A, 50/60 Hz common
​Maximum Power Consumption
​3.6 kW
Dimensions (One place rear angled stapling is supported on A4 and A3 only.)
​W 1163×D 788×H 1391 mm
​Weight (Optional)
​256 kg
Internal Controller
​Type
​Internal
Continuous Print Speed
​Depends on the Basic Specifications / Print Function
Printing Resolution
[PCL Driver]
  • Standard: 2400×2400 dpi, High Resolution: 2400×2400 dpi
​[Adobe® PostScript® 3™ Driver]
  • Standard: 2400×2400 dpi, High Resolution: 2400×2400 dpi
Page Description Language
​PCL, Adobe® PostScript® 3™
​Supported Operating System
​[PCL Driver]
  • Windows 10 (32 bit / 64 bit), Windows 8.1 (32 bit / 64 bit)
  • Windows 7 (32 bit / 64 bit) [Service Pack 1]
  • Windows Server 2019 (64 bit), Windows Server 2016 (64 bit)
  • Windows Server 2012 R2 (64 bit), Windows Server 2012 (64 bit)
  • Windows Server 2008 R2 (64 bit) [Service Pack 1]
  • Windows Server 2008 (32 bit / 64 bit) [Service Pack 2]
[Adobe® PostScript® 3™ Driver]
  • Windows 10 (32 bit / 64 bit), Windows 8.1 (32 bit / 64 bit)
  • Windows 7 (32 bit / 64 bit) [Service Pack 1]
  • Windows Server 2019 (64 bit), Windows Server 2016 (64 bit)
  • Windows Server 2012 R2 (64 bit), Windows Server 2012 (64 bit)
  • Windows Server 2008 R2 (64 bit) [Service Pack 1]
  • Windows Server 2008 (32 bit / 64 bit) [Service Pack 2]
  • macOS 10.15 / 10.14 / 10.13 / 10.12, OS X 10.11 / 10.10 / 10.9 / 10.8
[Mac OS X Driver]
  • macOS 10.15 / 10.14 / 10.13 / 10.12, OS X 10.11 / 10.10 / 10.9 / 10.8
Interface
Standard: Ethernet 1000BASE-T / 100BASE-TX / 10BASE-T×1, USB2.0×1
Optional: ​[Secondary Ethernet] Ethernet 1000BASE-T / 100BASE-TX / 10BASE-T×1
Scan Function
​Scan Resolution
​600×600 dpi, 400×400 dpi, 300×300 dpi, 200×200 dpi
​Scan Speed
​Same as the “Scan Speed” for the Duplex Automatic Document Feeder
Scanning Method
Store to folder (TWAIN interface support), Scan to PC, Scan to e-mail
Copy Function
​Scan Resolution
​600×600 dpi
​Printing Resolution
​600×600 dpi, Equivalent to 2400×2400 dpi ( When the Image Enhancement feature is enabled.)
First Copy Output Time
3.9 sec (A4) (When the original is set on the document glass and copies are output to the output tray of Finisher D6 or Finisher D6 with Booklet Maker.)
Offset Catch Tray (Optional)
Paper Size
Standard Size: Max A3, SRA3 (320×450 mm), Min A6 Custom Size: 100×148 mm to 330.2×488 mm
Paper Weight
52 to 300 gsm
Paper Capacity (64 gsm paper.)
500 Sheets
Duplex Automatic Document Feeder
Original Size / Paper Weight
Max: A3, 11×17", Min: A6(84×139.7 mm for custom size) 38 to 200 gsm (In Duplex: 50 to 200 gsm)
Capacity (64 gsm paper.)
250 sheets
Scan Speed
Copy: 100 ppm (A4 LEF, 1 Sided)
Scan: 1 sided: 135 ppm, 2 sided: 270 ppm [Fuji Xerox Standard Paper (A4), 200 dpi, to Folder.]
Print Server [GX Print Server for the B9 Series](Optional)
​Type
External
CPU
​Intel® Core™ i3 6100 Processor 3.7 GHz
Storage device
Hard disk: 1 TB, DVD Multi drive
Memory capacity
16 GB (Max 16 GB)
Server Operation System
Windows 10 IoT Enterprise (64 bit)
Page Description Language
Adobe® PostScript® 3™, PDF/VT-1, PDF/VT-2, PPML, VIPP (Used with optional software FreeFlow® VI Compose.)
Print Data Format
PS, PDF1.7, PDF/X-1a, PDF/X-3, PDF/X-4, PDF/X-5, EPS, TIFF, JPEG, IPDS (Optional) , PCL(Please contact our sales representative for supported PCL data type.)
Supported Operating System
Windows 10 (32 bit / 64 bit), Windows 8.1 (32 bit / 64 bit)
Windows 7 (32 bit / 64 bit) [Service Pack 1]
Windows Server 2019 (64 bit), Windows Server 2016 (64 bit)
Windows Server 2012 R2 (64 bit), Windows Server 2012 (64 bit)
Windows Server 2008 R2 (64 bit) [Service Pack 1]
Windows Server 2008 (32 bit / 64 bit) [Service Pack 2]
​macOS 10.15 / 10.14 / 10.13 / 10.12 , OS X 10.11 / 10.10 / 10.9
Interface
​Ethernet 1000BASE-T / 100BASE-TX / 10BASE-T×2, USB3.0×6, USB2.0×2
Network Protocol
TCP/IP (lpr / FTP / IPP (Used to work with FreeFlow® Digital Workflow Collection.) / SMB / HTTP), AppleTalk (AppleTalk is not supported by Mac OS X 10.6 or later.), Bonjour
​Power Supply
AC100-240 V +/-10 %, 2.5 A (100 V) / 1.1 A (240 V), 50/60 Hz common
Maximum Power Consumption
0.2 kW
Dimensions (Print Server only. Excludes LCD monitor, keyboard, and mouse.)
W 135×D 300×H 315 mm
Weight (Print Server only. Excludes LCD monitor, keyboard, and mouse.)
​6.8 kg
Finisher D6 / Finisher D6 Plus / Finisher D6 with Booklet Maker (Optional)
​Type
Output Tray: Sort / Stack
Finishing Tray: Sort (Offset available) / Stack (Offset available)
Booklet Tray:
  • Finisher D6: -
  • Finisher D6 Plus: -
  • Finisher D6 with Booklet Maker: Sort / Stack
Paper Size
Output Tray:
  • Standard Size: Max A3, SRA3 (320×450 mm), Min A6
  • Custom Size: 100×148 mm to 330.2×488 mm (Banner Printing on long paper of up to 330.2 x 660.4 mm is available. Banner Printing on long paper is available for B9136, B9125, and B9110 Copier/Printer.)
Finishing Tray:
  • Standard Size: Max A3, SRA3 (320×450 mm), Min A5
  • Custom Size: 148×148 mm to 330.2×488 mm
​Paper Weight
Output Tray: 52 to 350 gsm ( Banner Printing on long paper of 64 to 216 gsm is available. Banner Printing on long paper is available for B9136, B9125, and B9110 Copier/Printer.)
Finishing Tray: ​52 to 350 gsm
Paper Capacity (64 gsm paper)
Output Tray: 500 Sheets (A4)
Finishing Tray:
  • Finisher D6: [Without Stapling] A4: 3000 sheets JIS B4 or larger: 1500 sheets Mixed Size Stacking (When larger size sheets are stacked on top of smaller size sheets) : 350 sheets [With Stapling] A4: 200 sets or 3000 sheets JIS B4 or larger: 100 sets or 1500 sheets
  • Finisher D6 Plus, Finisher D6 with Booklet Maker: [Without Stapling] A4: 2000 sheets JIS B4 or larger: 1500 sheets Mixed Size Stacking (When larger size sheets are stacked on top of smaller size sheets) : 350 sheets [With Stapling] A4: 200 sets or 2000 sheets JIS B4 or larger: 100 sets or 1500 sheets
Booklet Tray:
  • Finisher D6, Finisher D6 Plus: -
  • Finisher D6 with Booklet Maker: 20 sets (Booklet tray capacity is 20 sets (16 sheets bind and below), 16 sets (17 to 20 sheets bind), 12 sets (21 to 25 sheets bind) and 10 sets (26 to 30 sheets bind))
​Staple
​Capacity: 100 sheets (65 sheets for sizes exceeding A4.) (90 gsm or less)
Paper Size:
  • Standard Size: Max A3, Min JIS B5
  • Custom Size: 182×148 mm to 297×431.8 mm
Paper Weight: 52 to 300 gsm
Position: Single Stapling (One place rear angled stapling is supported on A4 and A3 only), Dual stapling
Punch (Optional)
Number of Holes (The possible number of holes depends on the paper size.)
Paper Size:
  • Standard Size: 2-hole punch: JIS B5, A4, JIS B4, A3 3-hole punch: JIS B5, A4, JIS B4, A3 4-hole punch: A4, A3
  • Custom Size: 2-hole punch: 203.2×182 mm to 297×431.8 mm 3-hole punch: 254×182 mm to 297×431.8 mm 4-hole punch: 267×182 mm to 297×431.8 mm
Paper Weight: ​52 to 220 gsm
Booklet Finishing
Capacity (The capacity can decrease depending on type and weight of paper being used and other conditions.)
  • Finisher D6, Finisher D6 Plus: -
  • Finisher D6 with Booklet Maker: Saddle Staple: 30 sheets, Single fold: 5 sheets
Paper Size
  • Finisher D6, Finisher D6 Plus: -
  • Finisher D6 with Booklet Maker: Standard Size: Max A3, SRA3 (320×450 mm), Min JIS B5 Custom Size: 182×257 mm to 330.2×488 mm
Paper Weight
  • Finisher D6, Finisher D6 Plus: -
  • Finisher D6 with Booklet Maker: 52 to 300 gsm
​Power Supply
AC100-240 V +/- 10 %, 2.4-3.0 A (100 V) / 1.5-1.8 A (240 V), 50/60 Hz common
​Maximum Power Consumption
​300 W
Dimensions
​Finisher D6, Finisher D6 Plus: W 855×D 725×H 1200 mm
Finisher D6 with Booklet Maker: W 892×D 725×H 1200 mm
​Weight
​Finisher D6: 85 kg
Finisher D6 Plus: 90 kg
Finisher D6 with Booklet Maker: 105 kg​
Folder Unit CD2 (Optional)
​Z Fold Half Sheet
Paper Size: A3, JIS B4
Paper Weight: 52 to 105 gsm
Tri-fold
Paper Size: A4
​Paper Weight: 52 to 105 gsm
Paper Capacity (64 gsm paper): 30 sheets
Power Supply
AC100–240 V +/- 10 %, 0.8-1.0 A (100 V) / 0.5-0.6 A (240 V), 50/60 Hz common
​Maximum Power Consumption
​100 W
​Dimensions
W 232×D 725×H 992 mm
Weight
​55 kg
High Capacity Stacker A1 (Optional)
Paper Capacity (64 gsm paper)
Output Tray: 500 sheets
High Capacity Stacker - Stacker Cart: 5000 sheets
Paper Size
Output Tray
  • Standard Size: Max A3, SRA3 (320×450 mm), Min A6
  • Custom Size: 100×148 mm to 330.2×660.4 mm
High Capacity Stacker - Stacker Cart
  • Standard Size: Max A3, SRA3 (320×450 mm), Min JIS B5
  • Custom Size: 203×148 mm to 330.2×488 mm
Paper Weight
Output Tray: 52 to 350 gsm
​High Capacity Stacker - Stacker Cart: 52 to 350 gsm
​Power Supply
​AC100-240 V +/- 10 %, 1.18-1.5 A (100 V) / 0.8-0.96 A (240 V), 50/60 Hz common
Maximum Power Consumption
​150 W
Dimensions
​W 800×D 725×H 1042 mm
Weight (Includes Stacker Cart)
​155 kg
   Find out more about the Fuji Xerox B9136 / B9125 / B9110 / B9100, its features and what it can do.
