​Printer Type: 5-Colour 36" (914 mm)

Number of Nozzles: 15,360 nozzles (MBK: 5,120 nozzles; BK, C, M, Y: 2,560 nozzles each）

Maximum Print Resolution : 2400 × 1200 dpi

Nozzle Pitch: 1200 dpi (2 lines)

Line Accuracy (User adjustments is required. Printing environment and media must match those used for the adjustments. Paper required: Plain paper, CAD tracing paper, coated paper, CAD translucent matte film only.): ± 0.1% or less

Minimum Ink Droplet Size: 5 pl

Ink Capacity

• Sales Ink: 160 ml / 330 ml / 700 ml (MBK, BK, C, M, Y)
• Bundled Starter Ink: 330 ml (MBK) / 160 ml (BK, C, M, Y)

Ink Type: Pigment Ink

Printer Language

• SG Raster (Swift Graphic Raster)
• HP-GL/2
• HP RTL
• PDF (Ver. 1.7)
• JPEG (Ver. JFIF1.02)

Printing Solutions: Apple AirPrint, Direct Print Plus, Direct Print & Share, CPP Driver Select & Publisher Select, AutoCAD Optimized Printer Driver, Easy-PhotoPrint Editor, Canon PRINT Inkjet/SELPHY, Canon Print Service, Free Layout plus, PosterArtist Lite, imageRUNNER ADVANCE Direct Enlargement Copy

Management Solutions: Media Configuration Tool, Accounting Manager, Device Management Console, Quick Utility Box

Standard Interfaces (Built-in)

• USB A Port: USB Memory (Direct Print)
• USB B Port (Series B, 4 pins): Hi-Speed USB

                                                                 Full Speed (12 Mbit/sec)
                                                                 High Speed (480 Mbit/sec)
                                                                 Bulk Transfer

• Gigabit Ethernet: IEEE 802.3 10base-T

                                           IEEE 802.3u 100base-TX/Auto-Negotiation
                                           IEEE 802.3ab 1000base-T/Auto-Negotiation
                                           IEEE 802.3x Full Duplex
                                           ​SNMP, HTTP, FTP, TCP/IP (IPv4/IPv6)

• Wireless LAN: IEEE802.11 b/g/n

                                     WEP (64/128bit)
                                     WPA-PSK (TKIP/AES)
                                     WPA2-PSK (TKIP/AES)
Memory

• Standard: 128 GB
• Physical: 2 GB

Hard Disk: 500 GB (Encrypted)

Plain Paper

• CAD Drawings, A0: 34 sec [Fast (Custom Q5)]

                                               37 sec [Fast]
                                               1 min 4 sec [Standard]

• Poster, A0: 37 sec [Fast (Custom Q5)]

                                42 sec [Fast]
                                1 min 15 sec [Standard]

Heavyweight Coated Paper HG

• Poster, A0: 1 min 38 sec [Fast]

                                2 min 33 sec [Standard]

Glossy Photo Paper HG 170

• Poster, A0: 2 min 59 sec [Fast]

                                5 min 44 sec [Standard]

Media Feed and Output

• Roll Paper (Single): Front Load, Front Output
• Cut Sheet: Front Load, Front Output (Manual feed using media locking lever.)

Media Width (Roll / Cut Sheet): 152.4 ～ 917 mm

Media Thickness (Roll / Cut Sheet): 0.07 ～ 0.8 mm

Min. Printable Length

• Roll Paper: 101.6 mm (For cloth, canvas, tracing paper and translucent matte film media, minimum printable length is 200 mm.)
• Cut Sheet: 203.2 mm

Max. Printable Length

• Roll Paper: 18 m (Varies according to the OS and application.)
• Cut Sheet: 1.6 m

Maximum Outer Roll Diameter: 170 mm or less

Borderless Printing Width (Roll paper only): 152.4 ～ 917 mm

Margins (Recommended Area)

• Roll Paper: Top: 20 mm, Bottom: 3 mm, Side: 3 mm
• Cut Sheet (Apple AirPrint): Top: 20 mm, Bottom: 31 mm, Side: 3 mm
• Cut Sheet (Others): Top: 20 mm, Bottom: 20 mm, Side: 3 mm

Margins (Printable Area)

• Roll Paper: Top: 3 mm, Bottom: 3 mm, Side: 3 mm
• Roll Paper (Borderless Print): Top: 0 mm, Bottom: 0 mm, Side: 0 mm
• Cut Sheet (Apple AirPrint): Top: 3 mm, Bottom: 12.7 mm, Side: 3 mm
• Cut Sheet (Others): Top: 3 mm, Bottom: 20 mm, Side: 3 mm

Dimensions (W x D x H)

• Main Unit + Roll Unit + Stand + Basket: 1390 x 984 x 1168 mm (Basket Open)

                                                                                  1390 x 766 x 1168 mm (Basket Closed)

• Main Unit + Roll Unit + Stand + Stacker: 1390 x 1188 x 1168 mm (Basket Open)

                                                                                   1390 x 1122 x 1168 mm (Basket Closed)

• Roll Unit: 1374 x 336 x 318 mm

Weight

• Main Unit + Roll Unit + Stand + Basket: 124 kg
• Main Unit + Roll Unit + Stand + Stacker: 136 kg
• Roll Unit: 19 kg

Packaged Dimensions (W x D x H)

• Main Unit + Stand + Basket + Pallet: 1606 x 903 x 1061 mm
• Stacker: 1249 x 906 x 291 mm
• Roll Unit: 1524 x 562 x 461 mm

Packaged Weight

• Main Unit + Stand + Basket + Pallet: 153 kg
• Stacker: 24 kg
• Roll Unit: 26 kg

Power Supply: AC 100 - 240 V, 50 - 60 Hz

Power Consumption

• Printing: 115 W or less
• Sleep Mode: 2.0 W or less
• Power Off: 0.3 W or less

Operating Environment

• Temperature: 15 ～ 30 °C
• Humidity: 10 ～ 80 % RH (no dew condensation)

Acoustic Sound

• Acoustic Power (Measured using ISO 7779 standard by using 36 inch plain paper, standard mode and line drawing / text mode.): Operation: Approx. 69 dB
• Acoustic Pressure (Measured using ISO 7779 standard by using 36 inch plain paper, standard mode and line drawing / text mode.): Operation: Approx. 51 dB (A)

                                                             Standby: 35 dB (A) or less

Roll Unit (Required): RU-32

Stacker (Optional): SS-31

2"/3" Roll Holder (Optional)​: RH2-34

Print Head: PF-06

Cutter Blade: CT-07

Maintenance Cartridge: MC-30

Ink Tank

• PFI-8110 (160 ml) / PFI-8310 (330 ml) / PFI-8710 (700 ml)
• Matte Black / Black / Cyan / Magenta / Yellow
