Printer Type: 5-Colour, 24" / 610 mm
Number of Nozzles: 15,360 nozzles (MBK: 5120 nozzles; BK, C, M, Y: 2560 nozzles each)
Maximum Print Resolution: 2400 x 1200 dpi
Nozzle Pitch: 1200 dpi x 2
Line Accuracy:±0.1% or less
Minimum Ink Droplet Size: 5 pl
Ink Capacity

• Sales Ink: 130 ml / 300 ml (MBK, BK, C, M, Y)
• Bundled Starter Ink: 130 ml (MBK) / 90 ml (BK, C, M, Y)

Ink Type: Pigment Ink: Matte Black, Black, Cyan, Magenta, Yellow
Printer Language

• SG Raster (Swift Graphic Raster)
• HP-GL/2
• HP RTL
• PDF (Ver. 1.7)
• JPEG (Ver. JFIF 1.02)

Standard Interfaces (Built-in)

• USB A Port:

           USB Memory (Direct Print)

• USB B Port:

           Hi-Speed USB
           Full Speed (12 Mb/sec)
           High Speed (480 Mb/sec)
           Bulk Transfer
           Series B (4 pins)

• Gigabit Ethernet:

           IEEE 802.3 10base-T
           IEEE 802.3u 100base-TX/Auto-Negotiation
           IEEE 802.3ab 1000base-T/Auto-Negotiation
           IEEE 802.3x Full Duplex

• Wireless LAN:

           IEEE802.11n/g/b
Memory

• Standard: 128 GB
• Physical: 2 GB

Hard Disk: 500 GB

Media Feed Method

• Roll Paper (One Roll): Upper Load, Front Output
• Cut Sheet: Upper Load, Front Output
• (Manual feed using media locking lever)

Media Output (SD-23)

• Standard Position: 1 Sheet
• Folding Position: 20 sheets on A1 portrait
• Flat Position: 20 sheets on A2 landscape

Media Width (Roll / Cut Sheet): 203.2 - 610 mm
Media Thickness (Roll / Cut Sheet): 0.07 - 0.8 mm
Minimum Printable Length

• Roll Paper: 203.2 mm
• Cut Sheet: 279.4 mm

Maximum Printable Length

• Roll Paper: 18 m (varies according to the OS and application)
• Cut Sheet: 1.6 m

Maximum Outer Roll Diameter: 150 mm or less
Borderless Printing Width (Roll Only)

• Recommended: 515 mm (B2), 594 mm (A1), 10", 14", 17", 24"
• Printable: 257 mm (B4), 297 mm (A3), 329 mm (A3+), 420 mm (A2), 8", 12", 16", 20", 300 mm, 500 mm, 600 mm

Physical Dimensions & Weight (Include roll holder set, exclude ink and print head)

• Main Unit + Stand + Basket (SD-23):
• Approx. 982 x 887 x 1060 mm (Basket Open)
• Approx. 982 x 757 x 1060 mm (Basket Closed)
• Approx. 52 kg

Packaged Dimensions & Weight

• Main Unit + Pallet:

           Approx. 1152 x 913 x 705 mm
           Approx. 69 kg

• Stand + Basket:

           Approx. 1155 x 824 x 268 mm
           Approx. 18 kg

• Main Unit + Stand + Pallet:

           Approx. 1152 x 913 x 961 mm
           ​Approx. 87 kg

Power Supply: AC 100 - 240 V, 50 - 60 Hz
Power Consumption

• Operation: 69 W or less
• Sleep Mode: 3.6 W or less
• Power Off: 0.3 W or less

Operating Environment

• Temperature: 15 - 30°C
• Humidity: 10 - 80 % RH (no dew condensation)

Acoustic Sound (Measured using ISO 7779 standard)

• [Acoustic Pressure]

           Operation: 44 dB(A)
           (Plain Paper, Line Drawing; Print Priority - Standard)

• Standby: 35 dB(A) or less
• [Acoustic Power]

           Operation: 66 dB
           (Plain Paper, Line Drawing; Print Priority - Standard)

2"/3" Roll Holder (Optional): RH2-28
